Application:
Suitable for carious power wire, data cable, communication cable and other special cable core wire cabling twist, meanwhile completed center taping and side taping.
Specification:
| Model | HD-Φ630 | HD-Φ800 | HD-Φ1000 | HD-Φ1250 | |
| Use | Twist PVC and PE core wire, copper wire | ||||
| Pay off bobbin(mm) | Φ400-500 | Φ400-500 | Φ400-500-630 | Φ400-500-630 | |
| Take up bobbin(mm) | Φ630 | Φ800 | Φ1000 | Φ1250 | |
| Inlet wire Dia.(mm) | 0.5-3.0 | 0.5-5.0 | 0.5-5.0 | 0.6-8.0 | |
| Twisted wire Dia.(mm) | Φ10 | Φ15 | Φ20 | Φ25 | |
| Lay length | 20-160 | 30-300 | 30-300 | 30-450 | |
| Bow speed (RPM) | 700 | 500 | 500 | 500 | |
| Rising bobbin | Pneumatic | Hydraulic pressure | Hydraulic pressure | Hydraulic pressure | |
| Traverse wire | Double screw to traverse wire reciprocate | ||||
| Take up tension | Pneumatic | ||||
| Brake | Pneumatic | ||||
| Twist direction | S or Z | ||||
| Taping device | Center or side taping | ||||
| Taping material | It is suit for cotton paper, drawing tape, aluminum tape | ||||
| Weight (KG) | 3500 | 4800 | 5500 | 6500 | |
