The caterpillar is made from bending the thick screen board. Large strength of structure and beautiful appearance. The power system adopts four shifts, in order to match the different production place needs. Adopt the European style thin wall cylinder, beautiful appearance and reliable work.
| Model | HD-30 | HD-100 | HD-200 | HD-300 | HD-500 | HD-800 | HD-1250 |
| Cable diameter (mm) | 0.5-5 | 3-20 | 5-30 | 5-35 | 5-40 | 8-60 | 10-80 |
| Max traction (kg) | 30 | 100 | 200 | 300 | 500 | 800 | 1200 |
| Traction speed (m/min) | 0-100 1.5-100 | 0-200 1.5-200 | 1.5-150 | 2.3-150 | 2.3-100 | 2.3-100 | 0-100 2.3-100 |
| Contact length (mm) | 320 | 450 | 520 | 620 | 750 | 1200 | 1500 |
| Width (mm) | 50 | 60 | 70 | 70 | 80 | 100 | 120 |
| Number of cylinder (pair) | 1 | 3 | 3 | 3 | 3 | 5 | 5 |
| Motor power (kw) | 0.75 | 2.2 | 3 | 4 | 5.5 | 7.5 | 7.5 |
| Motor speed (rpm) | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Center height | 1000mm | 1000mm | 1000mm | 1000mm | 1000mm | 1000mm | 1000mm |
| Machine size (LXWXH) | 1280x630x1400 | 1430x760x1450 | 1450x700x1500 | 1500x700x1650 | 1800x930x1650 | 2300x1030x1780 | 3000x1230x1780 |
| Model | HD-1600 | HD-2000 | HD-2500 | HD-3200 | HD-4000 | HD-5000 |
| Cable diameter (mm) | 12-100 | 16-120 | 16-130 | 20-140 | 30-180 | 30-220 |
| Max traction (kg) | 1600 | 2000 | 2500 | 3200 | 4000 | 5000 |
| Traction speed (m/min) | 2.3-100 | 3-80 | 5-60 | 5-60 | 4-40 | 30 |
| Contact length (mm) | 1900 | 2100 | 2400 | 2900 | 3200 | 1200 |
| Width (mm) | 120 | 140 | 140 | 145 | 145 | 165 |
| Width (mm) | 120 | 140 | 140 | 145 | 165 | 180 |
| Number of cylinder (pair) | 6 | 7 | 8 | 9 | 10 | 11 |
| Motor power (kw) | 11 | 15 | 15 | 18.5 | 18.5 | 18.5 |
| Motor speed (rpm) | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Center height | 1000mm | 1000mm | 1000mm | 1000mm | 1000mm | 1000mm |
| Machine size (LXWXH) | 3330x1230x1850 | 3660x1300x1850 | 3990x1300x1850 | 4320x1300x1850 | 5000x1300x1900 | 5680x1300x1900 |
