Application：
This copper rod breakdown machine mainly used to process copper rod(Inletφ8.0mm).
| Inlet wire diameter | Ø8mm |
| Outlet wire diameter | Ø1.2-4mm Ø1.5-3.0mm(coiler) |
| Max output speed | 25m/s(no annealing) 22m/s(with annealing) |
| Capstan diameter | Ø450mm |
| Max dies | 13 |
| Die size | Ø40mm*25mm |
| Length of wire accumulated | 9m |
| Dual spooler dimension | PND500-630 |
| Main motor power | 250KW(DC) |
| Power of capstan motor | 75KW(DC) |
| Power of dual spooler motor | 2*30KW(DC) |
| Annealing power | 5000ADC 70V |
| Elongation ratio | 25%-32% |
| External dimension: length*width*height | 28000*5310*4200mm |
