Application
Flyer cone pay off , the bobbin is installed in two sets of wheel barrows on the right and left side of pay-off to carry out with one another. The core wire can be thrown out freely within the wire spool. Electric wire delivery ring is installed additionally when carrying out high-speed pay-off to help the core wire introduce smoothly. It is applied to the continuous pay-off of high-speed extruder.
Specification:
| Model | Flaange dia.of bobbin(mm) | load(kg) | wire diameter(mm) | wire diameter(mm) | speed(m/min) | <material< strong=””>material> | |
| power-driven feed wire | single core conductor | stranded wire /pvc wire | Mostorless pay off | Power-driven | power-driven feed wire | ||
| HD-50(M) | 400-500 | 250 | 0.4-2.6 | 1.0-4.0 | 400 | 1200 | Stainless steel or cast iron |
| HD-63(M) | 500-630 | 500 | 0.6-3.0 | 1.2-5.0 | 400 | 1200 | |
| HD-80(M) | 630-800 | 800 | 1.0-3.6 | 1.6-6.0 | 300 | 800 | |
| HD-125(M) | 800-1250 | 2000 | 3.0-10 | 200 | 400 | ||
