Machine tranmission : by high precision gears
Gears and bearing lubricating: oil spraying
Capstan and dies lubricating: fully immersion type
Capstan material: tungsten carbide
Machine boady structure: iron cast
Machine weight: 3000kg
Machine dimension: 2600mm*1200mm*1300mm(L*W*H)
| Inlet size/max | 2.6-3.0mm |
| Outlet size | 0.4-1.6mm |
| Drawing speed/max | 1800m/min |
| Dies number | 17pcs |
| Reduction area | 18.18%+13.5% |
| Cone diameter | 250㎜ |
| Fixed speed cone diameter | 250㎜ |
| Main motor | AC55kw |
