Application：
High speed planetary strander is mainly used to stranding control cable, signal cable, computer cable, etc., which can be used for twisting steel core aluminum strand, bare copper, bare aluminum wire, etc.
| 400 | 500 | 630 | |
| Single wire diameter | Ø 7 mm | Ø 8 mm | Ø 10 mm |
| Cage speed | 126 rpm | 105 rpm | 85 rpm |
| Stranding Pitch | 48-1315 mm | 40-1315 mm | 58-1280 mm |
| Max. Taping speed | 500 rpm | 500 rpm | 500 rpm |
| Taping pitch | 14.5-279.4mm | 14.5-279.4mm | 14.5-279.4 mm |
| Steel tape speed | 146-376 rpm | 146-376 rpm | 146-376 rpm |
| Pitch range of taping head | 14.5-279.4 mm | 14.5-279.4 mm | 14.5-279.4 mm |
| Specification of bobbin | 400 | 500 | 630 |
| Take-up bobbin | Ø800-1600 | Ø1000-2500 | Ø1000-3150 |
| Main motor power | 11-37 KW(AC) | 22-45 KW(AC) | 22-55 KW(AC) |
| Take up torque motor | 16-60 N.M. | 40-60 N.M. | 60-80 N.M. |
| Height of center | 1000mm | 1000mm | 1000mm |
