Reels

Category:

ABS bobbin：

Model Meterial Flange dia. Thickness Barrel Dia Overall length Inner width Hole dia. r Eccentricity
PN300 PS 300 15 140 180 150 40 7.0 30 50
PN400 ABS 400 16 200 300 250 40-56 10 65 75
PN400 ABS 400 16 200 300 250 55-56 10 65 75
PN400 ABS 400 16 200 155 120 55-56 10 65 75
PN500 ABS 500 20 250 300 250 56 12.5 70 93
PN500 ABS 500 20 250 375 315 56 12.5 70 93
PN500 ABS 500 25 250 250 250 56 10.5 66 76
PN630 ABS 630 25 475 400 400 56 12 78 101
PN630 ABS 630 25 375 315 315   12 78 101
PN630 ABS 630 25 475 415 415 56 12 78 101
PN800 ABS 800 35 400 500 500 80 15 112 160
PN1000 ABS 1000 35 500 630 630 80 14

Steel bobbin：

Model d1 d2 d3 d4 d5 e L1 L2 L3 a VdM³
400 400 160/200 71 36 8-16 112 300/236 250/200 15-20 60° 26.3/18.8
500 500 200/250 112 56 16-28 140 375/300 315/250 15-20 60° 51.9/36.8
560 560 224/280 112 56 16-28 140 425/335 355/280 15-20 60° 73.4/53.7
630 630 250/315 112 56 16-28 140 475/375 400/315 15-20 60° 105.1/72.5
700 710 355 160 80 28-40 160 530 450 20-40 60° 133.6
800 800 400 160 80 28-40 160 600 500 20-40 60° 188.5
1000 1000 500 160 80 28-40 160 750 630 20-40 60° 371.1
1120 1120 560 160 80 28-40 160 850 710 20-40 60° 524.6
1250 1250 630 160 80 28-40 160 950 800 20-40 60° 732.4
1400 1400 710 160 80 65 300 1060 900     1029.1
1600 1600 800 160 80 65 300 1080 1000     1508.0
1800 1800 1000 200   65 300 1320 1120     1970.1
2000 2000 1120     65 300 1500 1250     2695.5
2240 2240 1250     65 300 1700 1400     3799.1
2500 2500 1500     65 300 1900 1600     5026.5
2800 2800 1800 280 140 65 300 2120 1800     6503.1
3150 3150 1900 300 160 65 500 2300 2000     9915.6
